ABB Annular Heating Element
Model Ring heater 220V, 2x100 W - 7865312
Product Overview:
The Annular Heating Element is designed to heat the FE2 filter unit in modular gas sampling probe systems.
Prevents condensation in moist gases, reducing the risk of filter clogging and corrosion.
Easy to install using two half-shells secured with a wing screw.
Technical Specifications:
Power Supply: 230V AC, 50-60 Hz
Temperature (Unregulated): ~120°C to 180°C (at 20°C ambient temperature)
Ambient Temperature: Up to 56°C
Protection Rating: IP50
Material: Aluminum alloy housing, brass heating surface
Weight: Approx. 17 kg
Electrical Connection: Terminals via M20 cable gland (heat-resistant conductor required, <200°C)
Installation: Two half-shells placed around the FE2 filter unit and secured with a wing screw.
28000 EGP
EGP: 28000
Category: RING HEATER
Need help?
Call Us undefined
Monday - Friday 09:00 - 21:00
Product Overview:
The Annular Heating Element is designed to heat the FE2 filter unit in modular gas sampling probe systems.
Prevents condensation in moist gases, reducing the risk of filter clogging and corrosion.
Easy to install using two half-shells secured with a wing screw.
Technical Specifications:
Power Supply: 230V AC, 50-60 Hz
Temperature (Unregulated): ~120°C to 180°C (at 20°C ambient temperature)
Ambient Temperature: Up to 56°C
Protection Rating: IP50
Material: Aluminum alloy housing, brass heating surface
Weight: Approx. 17 kg
Electrical Connection: Terminals via M20 cable gland (heat-resistant conductor required, <200°C)
Installation: Two half-shells placed around the FE2 filter unit and secured with a wing screw.
