Bürkert 2/2‑Way Mini Solenoid Valve / 6013 A 3.0 EG MS
136022
Product Overview
A compact, direct‑acting, normally‑closed solenoid valve. Opens when energized, closes by spring. Ideal for shut‑off, dosing, filling, ventilating, or vacuum applications. Modular design allows individual or manifold installation
Technical Specifications
-
Port connection: G1/4 (1/4")
-
Pressure range: 0–14 bar (203 psi)
-
Voltage/Frequency: 230 V AC, 50 Hz, 10 W
-
Orifice: 3 mm; Kv ≈ 0.23 m³/h (≈3.8 L/min at Δp=1 bar)
-
Body material: Brass; Seal: PTFE (with FKM options)
-
Temperature range: –10 to +100 °C (standard); up to +180 °C with special options
-
Direct acting (no minimum pressure differential); suitable for vacuum
Coil: Vibration‑proof, energy‑saving 'Kick & Drop' available; IP65 with proper plug
