Product Overview:
The ELR 1-24DC/600AC-30 is a single-phase solid-state contactor designed by Phoenix Contact. It facilitates silent and wear-free switching of AC loads, making it ideal for applications requiring high switching frequencies and longevity. The device operates with a 24 V DC control input and can handle output currents up to 30 A, with an operating voltage range between 42 V AC and 660 V AC. It features zero-voltage switching to minimize electrical interference and is suitable for DIN rail mounting.

Technical Specifications:

• Input Voltage (Control): 24 V DC
• Input Voltage Range: 4 V DC to 32 V DC
• Input Current: Approximately 12 mA
• Output Voltage (Load): 42 V AC to 660 V AC
• Output Current: Up to 30 A
• Switching Frequency: Up to 25 Hz
• Operating Temperature Range: -30°C to +70°C
• Mounting: DIN rail mounting
• Dimensions (W x H x D): 22.5 mm x 103 mm x 103 mm
• Features: Zero-voltage switching, green LED operating voltage display
